SiCore Dynamics

45-390 V High-Voltage DC-DC Boost Module

Adjustable capacitor-charging supply with protected high-voltage output

A compact power-electronics module documented from the supplied archived product page. The specifications below separate confirmed ratings from operating guidance and identify the exact module variant where the source page contains multiple options.

Cotizar

Topology

High-voltage DC-DC boost converter

Input voltage

8-32 VDC

Single-output range

45-390 VDC adjustable

Dual-output option

+/-45-390 VDC; up to 780 V differential

Input over-current protection

Activates above approximately 4.5 A and reduces output voltage

Output over-voltage protection

Activates above approximately 410 V and reduces output voltage
